The TE239 is designed for checking the frequency response of the modulation depth and the uniformity of modulation depth of HDTV cameras. The test chart consists of multiburst fields, which are distributed over a 16:9 picture area. The fields are arranged in horizontal and vertical directions in order to measure resolution in both directions.
*The exact layout and dimensions may differ from the illustration above.
