In-Cabin Testing – Driving Safety and Experience in Automotive

In-Cabin Testing – Driving Safety and Experience in Automotive

As the automotive industry accelerates toward autonomous driving, in-cabin monitoring systems are becoming mission-critical. Advanced driver and occupant monitoring solutions (DMS/OMS) rely on high-performance camera systems to ensure safety, comfort, and compliance with evolving regulations such as the EU’s General Safety Regulation.

In-cabin testing plays a key role in validating these systems under real-world conditions. From detecting driver drowsiness and distraction to monitoring occupant position and behavior, camera performance must remain reliable, even in challenging low-light environments. Critical image quality parameters such as resolution (SFR), distortion, dynamic range (OECF), noise (SNR), and timing accuracy directly impact system performance. In addition, the use of near-infrared (NIR) technologies demands precise calibration and testing setups to guarantee consistent results.

Need help testing image quality in-cabin?

Find the right products and services for testing an in-cabin camera system.

Analysis Software

Use the iQ-Analyzer-X image quality analysis software to evaluate your camera test results.

Test Services

Get professional camera testing with our image quality test lab, one of the world's largest independent camera test labs.

Testing Solutions for In-Cabin Camera Systems

LE7 lighbox for OECF measurements

LE7 VIS-IR

A uniform lightbox using iQ-LED technology for transparent test chart illumination.
iQ-Flatlight

iQ-Flatlight VIS-IR

A spectrally programmable iQ-LED light source for test chart illumination

GEOCAL IR

GEOCAL IR

Geometric camera calibrations using a compact device with a beam-expanded laser and a diffractive optical element.
Vega

VEGA IR

A unique DC-powered LED light source for evaluating camera systems with extremely short exposure times and extended IR capabilities will be available soon.
Arcturus illumination device - automotive in-cabin testing

Arcturus

The Arcturus high-intensity light source is a light source in the Vega line that has extremely high intensity and consistency.
Set up cameras inside the chamber

iQ-Climate Chamber

The iQ-Climate Chamber is used to test camera systems in a variety of temperature conditions.
iQ-Headturner for webcam tests

iQ-Headturner

Control the movement of the mannequin heads and optimize webcam image quality performance measurements.
camSPECS for spectral sensitivity measurements

camSPECS

An advanced device for more efficient spectral sensitivity measurements.
TE292 Test chart

TE292

Spectral sensitivity measurements with iQ-LED
TE283C Test Chart

TE283C

A slanted edge chart for fisheye cameras
TE269 V3 Test Chart

TE269

OECF 36 Chart following ISO 14524/15739 and IEC 62676-5
